Product Introduction
Purity PSCM double suction split case centrifugal pump is engineered with an axially split volute casing design, allowing easy access to internal components and significantly simplifying maintenance. Its impeller is available in AISI 304 stainless steel or HT250 cast iron, offering customizable material options to meet different operating conditions, fluid characteristics, and durability requirements.
The PSCM double suction centrifugal pump body is constructed from HT250 and finished with a high quality anti-corrosion coating, providing excellent resistance to rust, chemical exposure, and harsh working environments. This durable surface treatment ensures long-term operational reliability, making the double-suction centrifugal pump well-suited for municipal water supply, HVAC systems, industrial circulation, and general fluid transfer applications.
To enhance sealing performance and extend service life, Purity PSCM high quality double suction centrifugal pump is equipped with a shaft protection sleeve at the sealing area. Users can choose between a mechanical seal or packing seal based on system pressure, fluid properties, and maintenance preferences. This flexible sealing configuration helps minimize leakage, reduce downtime, and support stable pump operation under varying conditions.
The Purity PSCM double suction split case centrifugal pump uses grease-lubricated rolling bearings with a long-life sealed structure. This design effectively isolates internal components from liquid intrusion, protecting the bearings and other core parts from contamination and wear. As a result, maintenance frequency is reduced, operating stability is enhanced, and the overall service lifespan of the pump is extended.
Purity is one of double suction centrifugal pump factories in China,specializing in producing high quality centrifugal pumps that are highly regarded by overseas customers.
